Toro DDCWP 4 Station 9V Battery Operated Controller (DDCWP-4-9V)

Features & Benefits

Finally, a battery-powered, waterproof controller that programs just like its A.C. counterpart! Introducing the DDCWP Series, Toro's waterproof version of the popular DDC controller series. Using latching solenoids and battery power, the DDCWP is 100% waterproof to IP68 standards, making it ideal for mounting in valve boxes or outside. Available 4-station models, the DDCWP waterproof controller features an exclusive, patent-pending virtual dial interface that guides a user through simple programming functions. A convenient mounting bracket and waterproof connectors are included with each model.

Product Details

• Fully waterproof and submersible to 2m (6'), per IP68 standard
• Convenient mounting bracket included for easy installation in valve boxes or other tight spaces
• Compatible with wired rain sensor
• Waterproof connectors included for all stations, master valve, and optional sensor
• 2 x 9V alkaline batteries provide sufficient power to last entire irrigation season; (program retention completely independent using internal coin battery)
• Low battery indicator visible in LCD screen
• Unique power feature verifies sufficient voltage level for turning stations off before turning any stations on
• Toro exclusive "digital dial" technology simulates the simplicity of a mechanical dial
• Large LCD display
• 3 independent, stacking programs, easily identified within the "digital dial" interface
• 3 Start Times per Program
• 1 to 240-minute run times
• Multiple watering days options
  • 365-day calendar
  • 7-day calendar, 14-day interval
  • Odd/Even day watering, with 31st-day exclusion
• 0 to 200% Seasonal Adjust (Water Budget) setting in 10% increments, by program
• AM/PM or 24-hour time option
• True manual and manual program start
• Built-in Rain delay
• Programmable Master Valve
• Convenient program review feature
• Easy to read faceplate in English and symbols (multi-language overlays on A.C. models)
• 5 Year program retention, with onboard coin battery
• Default program if loss of power occurs
• Conforms to electromagnetic compatibility directives (CEE, FCC, and C-Tick)

Electrical Specifications

• Operates using 2 x 9V alkaline batteries (not supplied).
• Operates one Toro latching solenoid per station and one latching solenoid-equipped master valve
• Maximum distance between controller and a latching solenoid using 1.0 mm2 (AWG #18) sized wire: 60 m (197')
• The controller is compatible with all Toro valves accepting latching solenoids (model DCLS or equivalent) and selects competitive valve models/latching solenoids
• Accepts Toro TRS RainSensor and other wired rain sensors

Mechanical Specifications

• Weight without 9-volt batteries: 672 grams (23.3 ounces)
• Dimensions:
  • 12.6 x 14.5 x 4.9cm
  • 5" x 53/4" x 115/16" (H x W x D)
• Operating temperature: 0 - 60C (32 - 140 F)
